MasterLine 8

Crafted of masters

MasterLine 8 is a high-quality window system that links countless design options to best-in-class performance and unrivalled production speed. This next generation of aluminium windows is available in three insulation levels to match any project demands.

Features / Highlights

Our flashship product,with a wide field of applicability
Excellent thermal and AWW performances

Highly competitive price-quality ratio

Product Solution

Functional window

The standard product offers o functional design,which means it will fit any building style.

Deco

This product has been developed to mimic the look of wooden windows,and the Deco variant replicates the more chamfer details

Hidden Vent

The Hidden Vent is an openable element that looks like a fixed element from the outside, for more architectural symmetry and a clean look.

Renaissance

This product has been developed to mimic the look of wooden windows,and the Renaissance variant replicates the curves and steps of milled woord detailing

Ventilation Vent

Preventing overheating while remaining safe for anyone to use, the ventilation vent is an easy to integrate solution

High Insulation

This product line spans a large range of insulation values. The standard variant is already sufficient in a lot of regions, but the High Insulation variant improves this even further.

High Insulation +

This product line spans a large range of insulation values. The High Insulation + variant enables passive haouse levels energy preservation

Designs

Properties

TECHNICAL CHARACTERISTICS
Style Variants		WINDOWS		DOORS
Style Variants		FUNCTIONAL	HIDDEN VENT	TERRACE DOORS	FLUSH DOORS	XL PIVOT
Min. visible width inward opening window or door	Frame	2 1/16”	3 1/8”	2 3/8”	2 11/16”	2 11/16”
Min. visible width inward opening window or door	Vent	1 7/16”	–	2 5/8”	3 1/16”	5 1/16”
Min. visible width outward opening window or door	Frame	13/16”	–	13/16”	1 11/16”	2 11/16”
Min. visible width outward opening window or door	Vent	4 5/8”	–	4 7/16”	4 1/8”	6 1/8”
Min. visible width T-profile		3 1/8”	4 3/16”	3 1/8”	3 1/8”	3 1/8”
Overall system depth window or door	Frame	3 1/16”
Overall system depth window or door	Vent	3 7/16”	3 1/16”	3 7/16”	3 1/16”	3 1/16”
Rebate height		1 1/16”
Glass thickness	Frame	up to 2 7/8”	up to 2 7/8”	up to 2 7/8”	up to 2 7/8”	2 7/16”
Glass thickness	Vent	up to 213/16”	up 2 1/4”	up to 2 13/16”	up to 2 7/16”	up to 2 7/16”
Glazing method		dry glazing with EPDM or neutral silicones
Thermal insulation		omega-shaped glass fibre reinforced polyamide strips HI+ version: glass fibre reinforced noryl strips 1 9/16” or 1 1/2” depending on profile			1 1/4”	–

Window Handle Purity

Performance

PERFORMANCE SPECIFICATIONS				FIXED		OPERABLE		TERRACE DOOR		FLUSH DOOR		XL PIVOT
	ENERGY
	Thermal Insulation (2) (Btu/hr∙ft²∙°F) per NFRC 102			Double	Triple	Double	Triple	Double	Triple	Double	Triple	Double	Triple
		Fixed	Uw	0.22	0.15
			SHGC	0.16	0.19
		Open In	Uw			0.25	0.19	0.22	0.15	0.25	0.20	0.37	0.31
			SHGC			0.15	0.16	0.17	0.16	0.15	0.16	0.18	0.18
		Open out	Uw			0.29	0.24	0.26	0.20	0.25	0.20	0.37	0.31
			SHGC			0.11	0.10	0.15	0.16	0.17	0.16	0.18	0.18
	COMPORT
	Acoustic performance(3) ASTM E90- 09/1332		STC	50		49		43		43		–
			OITC	44		43		35		35		–
	Air tightness, max. test pressure(4) (cfm/ft²			0.04		0.04		0.04		–		0.14
	Water tightness(5) (psf)			15		15		20		–		2.92
	AAMA Rating AAMA/WDMA/CSA 101/I.S.2/A440, NAFS			AW PG100		AW PG100		AW PG60		–		R PG25
This table shows classes and values of performances, which can be achieved for specific configurations and opening types. (1) All results based on gateway sizes; vary depending on glass/profile combinations \| Above Uw & SHGC values do not necessarily work in combination. (2) Uw is the measure of heat transfer through the fenestration product with glass. The lower the Uw, the better the thermal insulation of the element. (3) The sound reduction index measures the capacity of the sound reduction performance of the frame and glass. (4) The air tightness test measures the volume of air that would pass through a closed window at a certain air pressure. (5) Water tightness testing applies a specified air pressure differential while simultaneously spraying water on to the ext. face of the assembly at the rate of 5 gal/hr/ft2.
